AISI Grain Oriented Electrical Steel Strip For Transformer Core B27p100 27qg100

Name: AISI Grain Oriented Electrical Steel Strip For Transformer Core B27p100 27qg100
Brand: Jiangsu Baowu new Material Co., LTD
SKU: Grain Oriented Electrical Silicon Steel Coil
Price: 332.00 USD
Availability: InStock

Brand Name:	Bao Steel
Model Number:	Grain Oriented Electrical Silicon Steel Coil
MOQ:	1 ton
Price:	Elaborate
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	250 tons/week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Name:

Oriented Electrical Silicon Steel Coil

Tolerance:

±1%

Surface Treatment:

Coated

Model Number:

B27p100 27qg100

Tickness:

0.2 - 0.7 Mm

Processing Service:

Bending, Welding, Decoiling, Cutting, Punching

Application:

Transformer Core

Standard:

AISI ASTM

Packaging Details:

Wooden pallets and container

Supply Ability:

250 tons/week

Highlight:

B27p100 Grain-Oriented Electrical Steel

Electrical Steel Strip 27qg100

B27p100 silicon steel strip

Product Description

AISI Grain Oriented Electrical Steel Strip For Transformer Core B27p100 27qg100 0

the saturation magnetization, and of embrittling the alloy when the silicon additions exceed about 2 wt.%. The embrittling effects of silicon make it difficult to produce silicon steels with more than about 3 wt.% silicon. The silicon steels are produced in two forms, highly textured grain-oriented alloys and alloys in which the grains are not oriented. Grain orientation is carried out to align the magnetic easy axis.

Type	Nominal thickness (mm)	Tensile strength L (N/mm2)	Yield strength L (N/mm2)	Elongation L (%)	Hardness HV1	Number of bends	Lamination factor (%)
Common series	0.27	335	305	12	190	25	97.5
Common series	0.3	345	310	12	190	20	98
High induction series	0.23	351	316	10	197	22	96.5
	0.27	350	325	12	195	20	97.5
	0.3	350	310	11	195	17	98
Domain refined high induction series	0.23	353	326	12	195	19	96.5
Domain refined high induction series	0.27	355	330	10	200	18	97.5

AISI Grain Oriented Electrical Steel Strip For Transformer Core B27p100 27qg100 1

AISI Grain Oriented Electrical Steel Strip For Transformer Core B27p100 27qg100 2

AISI Grain Oriented Electrical Steel Strip For Transformer Core B27p100 27qg100 3

AISI Grain Oriented Electrical Steel Strip For Transformer Core B27p100 27qg100 4

AISI Grain Oriented Electrical Steel Strip For Transformer Core B27p100 27qg100 5
