products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Carbon Steel Coil
Created with Pixso.

Hot Rolled 45# C45E SAE1045 4-120mm Carbon Steel Plate For General Machinery Parts

Hot Rolled 45# C45E SAE1045 4-120mm Carbon Steel Plate For General Machinery Parts

Hot Rolled 45# C45E SAE1045 4-120mm Carbon Steel Plate For General Machinery Parts

Brand Name: Baosteel Tisco
Model Number: SAE 1020
MOQ: 1 Ton
Price: Negotiatble
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 5000 tons per month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO CE
Material:
1045 Carbon Steel
Width:
1000-2500mm
Length:
6-13m
Standard:
ASTM,AISI，SAE
Application:
Making Die-board,general Machinery Parts
Tehnique:
Hot Rolled;cold Rolled
Elongation At Break:
15 %
Reduction Of Area:
40 %
Packaging Details:
Standard sea packing or per to client request
Supply Ability:
5000 tons per month
Highlight:

120mm Carbon Steel Plate

,

SAE1045 Carbon Steel Plate

,

SAE1045 Carbon Steel sheet

Product Description

SAE 1045/AISI 1045 Carbon Steel is a medium carbon steel which is characterized by good weldability, good machinability, high strength and impact properties in either the normalized or hot forged condition.



Description

Material: 2mm 5mm 6mm 10mm 20mm astm a36 mild carbon steel plate
Thickness: 0.2-500mm,etc
Width : 1000-4000mm,etc
Length: 2000mm, 2438mm, 3000mm, 3500,6000mm,12000mm,or rolled,etc etc
Standard: ASTM,AISI,JIS,GB, DIN,EN
Surface: Black painted,PE coated,Galvanized,color coated,
anti rust varnished,anti rust oiled,checkered,etc
Technique: Cold Rolled, Hot Rolled
Certification: ISO, SGS,BV
price terms: FOB,CRF,CIF,EXW all acceptable
Delivery Detail: inventory About 5-7; custom-made 25-30
Loading port: any port in China
Packing: standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
Payment Terms: T/T, L/C at sight,West Union,D/P,D/A,Paypal
Container size: 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)





Equivalent Grade

GB DIN NF SS JIS BS AISI ISO
45# 1.0503 C45 1650 S45C IC45/080A47 1045 C45E4







Chemical Analysis

NO. C Mn Si Cr Cu Ni P S
Aisi 1045 0.43~0.50 0.6~0.9 0.10~0.60       ≤0.40 ≤ 0.50
DIN1.0503 0.42~0.48 0.6~0.9 0.15~0.35 ≤0.15 ≤0.3 ≤0.2
JIS S45C 0.42~0.50 0.5~0.8 ≤0.40 ≤0.40   ≤ 0.4
GB45 0.42~0.50 0.5~0.8 0.17~0.37 ≤0.25 ≤0.25 ≤0.3 ≤0.035 ≤0.035



Mechanical properties

Annealing Forging Tempering and Hardening Normalization

Subcritical annealing:

650~700

Isothermal annealing:

820~860

1100~850

Tempering: 550~660

Hardening : 820~860 water

 840~880



Heat Treatment

Soft annealing: heat to 550-650°C, cool slowly.

Hardness after annealing: Max. 269HB

Hardening: 820 - 870 °C

Normalizing temperature: 840-870°C

Hot Rolled 45# C45E SAE1045 4-120mm Carbon Steel Plate For General Machinery Parts 0

Hot Rolled 45# C45E SAE1045 4-120mm Carbon Steel Plate For General Machinery Parts 1

Hot Rolled 45# C45E SAE1045 4-120mm Carbon Steel Plate For General Machinery Parts 2

Hot Rolled 45# C45E SAE1045 4-120mm Carbon Steel Plate For General Machinery Parts 3
