P20 1.2311Die SteelMold Steel Alloy Steel Material Engineered for Durable Mold Components and Tooling Solutions Providing Excellent Heat Treatment Capabilities

Product Description:

P20 mold steel is a commonly used pre-hardened plastic mold steel, designated P20 in the US and 3Cr2Mo in China. Here is a detailed description:

Performance Characteristics

Hardness and Wear Resistance: Pre-hardened, it possesses high hardness and wear resistance, capable of withstanding wear during mold use.

Toughness: It has high impact toughness and ductility, is not prone to brittle fracture, and can withstand a certain amount of impact force.

Machining Performance: Easy to cut, drill, and mill, meeting the complex machining requirements of mold manufacturing.

Polishing Performance: Smooth surface, easy to polish, resulting in high-quality mold surfaces, suitable for molds with specific appearance requirements.

Dimensional Stability: Minimal dimensional changes during heat treatment, ensuring mold precision and stability.

Steel Purity: Vacuum degassing and refining ensures high steel purity, suitable for plastic molds requiring polishing or texturing.

Supply Condition: P20 mold steel is typically supplied in a pre-hardened state, requiring no further heat treatment before use in mold processing. Its supply hardness is generally between HRC28-34, although some sources indicate HRC30-35 or 285-330HB (30-36HRC).

Heat treatment method: To improve mold life, pre-hardened steel can be hardened by quenching followed by low-temperature tempering. During quenching, preheat at 500-600℃ for 2-4 hours, then hold at 850-880℃ for at least 2 hours. Cool in oil to 50-100℃, then air-cool. The hardness after quenching can reach 50-52 HRC. To prevent cracking, immediate low-temperature tempering at 200℃ is necessary. After tempering, the hardness can remain above 48 HRC. Alternatively, nitriding can be performed, achieving a surface hardness of 650-700 HV (57-60 HRC), and increasing the mold life to over 1 million cycles.

PLASTIC MOULD STEEL: 1.2311, 1.2312, 1.2738, P20, 1.2083, 1.2316, NAK80, P40, 1.2738HH

HOT WORK MOULD STEEL: 1.2344, SKD61, H13, H11, FDAC, 8407

COLD WORL MOULD STEEL: SKD11, D3, SKS3, 1.2080, 1.2379, CR12MOV, O1, D2

STRUCTURAL ALLOY STEEL: 4140, 20CR, 40Cr, 35CrMo, 42CrMo, 38CrmoAi, SCM440, SCM420, 1.7225

CARBON STEEL &: Q235, Gcr15, S45C, S50C, S55C

CNC surface grinding machine, NC side boring machine, Band saw, CNC double head machine, Vertical Band saw, CNC milling machine, Double alloy saw blade, wireless remote control crane, Magnetic chuck

Applications:

Suitable for thermoplastic injection molds, extrusion molds, and thermoplastic blow molds. Commonly used in molds for manufacturing plastic products such as television housings, washing machine casings, refrigerator inner shells, and buckets. It is also a key component of heavy-duty molds.

Customization:

BAOSTELL offers customizable Mold Steel products, including models such as SKD11, Cr12MoV, Cr8, 1.2379, 5Cr4Mo3SiMnVAl, and Cr12, all originating from China. Our mold steel is a high-quality alloy steel material known for its exceptional wear-resistant tool steel properties, making it ideal for applications requiring durable and long-lasting performance.

Certified under ISO 9001, our mold steel products deliver superior impact toughness of ≥ 20 J/cm² and a density ranging from 7.7 to 7.9 G/cm³. With a yield strength between 600-1000 MPa, this abrasive tool steel is designed to withstand rigorous use and provide excellent grinding tool steel capabilities.

We accommodate orders starting from a minimum quantity of 1 TON, with pricing negotiable to meet your budget and project requirements. Packaging is handled with standard sea packing or customized according to client requests, ensuring safe and secure delivery.

Our payment terms are flexible, with TT accepted to facilitate smooth transactions. Trust BAOSTELL for premium mold steel solutions that combine strength, durability, and precision for all your tooling needs.

Support and Services:

Our Mold Steel products are backed by comprehensive technical support and services designed to ensure optimal performance and longevity. We provide expert guidance on material selection, heat treatment processes, and machining techniques tailored to your specific application needs. Our technical team is available to assist with troubleshooting, maintenance recommendations, and process optimization to maximize the efficiency and durability of your molds. Additionally, we offer customized solutions and value-added services, including material testing and certification, to meet stringent quality standards. Partner with us to leverage our expertise and enhance the reliability and productivity of your mold steel components.

Packing and Shipping:

Our Mold Steel products are carefully packaged to ensure maximum protection during transportation. Each item is securely wrapped in protective materials to prevent any damage from moisture, dust, or impact.

The packaging includes sturdy, reinforced boxes that are clearly labeled with product details and handling instructions. For added safety, we use custom foam inserts or padding to keep the mold steel components stable and secure inside the package.

Shipping is handled through reliable carriers with tracking options available to monitor your order’s progress. We offer various shipping methods to meet your timing and budget requirements, ensuring your Mold Steel products arrive on time and in perfect condition.

For international shipments, all necessary customs documentation and regulations compliance are managed by our logistics team to facilitate smooth delivery across borders.

FAQ:

Q1: What is the brand name and model number of this mold steel?

A1: The mold steel is branded as BAOSTELL, and the model numbers include SKD11, Cr12MoV, Cr8, 1.2379, 5Cr4Mo3SiMnVAl, and Cr12.

Q2: Where is the BAOSTELL mold steel manufactured?

A2: The BAOSTELL mold steel is manufactured in China.

Q3: Does the mold steel have any certifications?

A3: Yes, the BAOSTELL mold steel is certified with ISO 9001, ensuring quality management standards.

Q4: What is the minimum order quantity and payment terms for this product?

A4: The minimum order quantity is 1 TON, and the payment terms are typically by TT (Telegraphic Transfer).

Q5: How is the mold steel packaged for shipment?

A5: The mold steel is packaged either in standard sea packing or according to the client's specific requests.
